SN93100

Description

Sonix SN93100 series is a 2.4GHz wireless multi-media processor that target on wireless transmission for video, audio and data applications. It supports at least 3 popular types of 2.4GHz RF transceiver, including Nordic® nRF24L01, AMICCOM® A7121, MuChip® MV400. Within bandwidth limit of 2Mbps, 3Mbps and 4Mbps data rate for each brand RF transceiver, SN93100 supports 1-way video, 2-way audio and 2-way data transmission. SN93100 implements most popular LCD panel interfaces and supports ISP CMOS sensor interface. For PC peripheral applications, it supports USB 1.1 interface and follow UVC/UAC driver-less class compliance of Microsoft® XP® SP2 or VISTA® OS.
